Data from marine grab samples collected during the AUPASED surveys

Date 2020-06
Author(s) Michel GuillaumeORCID1, Le Bot SophieORCID1, Lesourd Sandric2, Legrain Magalie2, Levaillant Romain1, Simon Michel1, Lafite RobertORCID1
Affiliation(s) 1 : Normandie Univ, UNIROUEN, UNICAEN, CNRS, M2C, 76000 Rouen, France
2 : Normandie Univ, UNICAEN, UNIROUEN, CNRS, M2C, 14000 Caen, France
DOI 10.17882/74515
Publisher SEANOE
Keyword(s) Sediment, Estuaries, Marine habitats, Granulometric analyses
Abstract

Ground truth data are considered as highly valuable inputs for seabed sediment mapping. The AUPASED project (Faisabilité de la détermination automatique de paramètres sédimentaires dans le contexte de domaines estuariens - CNRS/OFB - France) aims to test and explore cartographic methods to map estuarine domains. These domains are considered as transitions between the continent and the marine domain. It implies a complex processes and high physical, hydrodynamic, sedimentary and biologic gradient which influence the sediment and morphological variations of the seabed. Cartography of three systems, Orne estuary, Somme Bay and the Belon estuary (Atlantic and English Channel coast of France) has been performed with acoustic mapping tools. The interpretation of the seabed backscatter for seabed sediment mapping requires ground truth data and especially sediment samples.

During the three AUPASED surveys, a total of 196 sediment samples were collected with a 50 kg Shipek grab (operated form the R/V “Haliotis”, 15 samples) and with a 25 kg Van Veen grab (operated from the R/V “Monod”, 161 samples). Once aboard, supernatant was removed after a short period of decantation. Then, each sediment samples were transferred into a plastic bag stored into attached lid containers. The 20 remaining samples have been collected at low tide and directly transferred into plastic bags.

Granulometric analyses of sediment samples have been performed at Caen University, in M2C laboratory. The first granulometric analysis is a mechanical sieving of the sediments performed with a Retsch AS300 Control. Before the mechanical sieving, sediment samples were washed to separate the sediment fraction smaller than 63 µm from the bulk sample. Then both fractions were dried, weighted and stored. Sediment fractions coarser than 63 µm were sifted by using a column of 26 sieves with mesh size ranging from 20 mm to 63 µm (full list is: 20 mm – 16 mm – 12.5 mm – 10 mm – 8 mm – 6.3 mm – 5 mm – 4 mm – 3.150 mm – 2.5 mm – 2 mm – 1.6 mm – 1.250 mm – 1 mm – 0.800 mm – 0.630 mm – 0.500 mm – 0.400 mm – 0.315 mm – 0.250 mm – 0.200 mm – 0.160 mm – 0.125 mm – 0.100 mm – 0.080 mm – 0.063 mm). For each sieve, the sieve residual was weighted and stored. The sediment fraction smaller than 2 mm was also analysed by Laser Granulometry with a particle size analyser LS13320 and the Aqueous Liquid Module (ALM) from Beckman Coulter. Calcimetric analyses have been performed on bulk sample using a Bernard Calcimeter.

All granulometry results from mechanical sieving and Laser Granulometry have been processed with GRADISTAT v8.0 (Blott & Pye, 2001). Data processing have been performed by using the ‘Single Sample Data Input’. All ‘Single Sample Statistics’ results produced were exported as PDF and have been synthetized within this published database.

The present CSV files corresponds each to one sediment sample database associated to one survey. All CSV database includes the same following information ; Survey name, Sample ID, Longitude, Latitude, X, Y, Sampling tool, Analysis method (mechanical sieving or laser), Total sample weight sieved (g), % of weight for each sieve mesh size (mm) listed above and % in volume for Laser analysis, Textural group, Sediment Name, Gravel content (%), Sand content (%), Mud content (%), Lithoclastic content (%) for sediment fraction larger than 2mm, Shell content (%) for sediment fraction larger than 2mm and total bulk carbonate (%). Samples with label starting at 100 correspond to those collected by the R/V ‘Haliotis’ during the AUPASED2 and AUPASED3 surveys. Samples with label starting at 200 are those sampled at low tide during the AUPASED3 survey. Samples collected at low tide during AUPASED1 are included in the global list. All D50, D90, Mean grain size, Sorting and Skewness parameters are included in both geometric (µm) and logarithmic (phi) units. Gravel, Sand and Mud are defined in GRADISTAT v8.0 by following the sediment size scale modified from Udden (1914) and Wentworth (1922). Textural group and Sediment Name are defined in GRADISTAT v8.0 according to Folk (1954). Coordinates are expressed in World Mercator WGS84 decimal degrees for Latitude and Longitude and in meters for X and Y with Lambert-93 RFG93 projection. CSV cells filled with n.a. corresponds to samples without information in the specified column.

Licence CC-BY-NC-SA
Utilisation Data are published without any warranty, express or implied. The user assumes all risk arising from his/her use of data. Data are intended to be research-quality and include estimates of data quality and accuracy, but it is possible that these estimates or the data themselves contain errors. It is the sole responsibility of the user to assess if the data are appropriate for his/her use, and to interpret the data, data quality, and data accuracy accordingly. Authors welcome users to ask questions and report problems.
Acknowledgments Laboratory CNRS M2C “Coastal and Continental Mophodynamics”. The authors also want to thank the R/V ‘Haliotis’ crew for collecting data and for their implication in the three surveys, as well as TGIR FOF and CNFC.
Data
File Size Format Processing Access
23 KB CSV Quality controlled data Access on demand until 2022-06-01
Top of the page

How to cite

Michel Guillaume, Le Bot Sophie, Lesourd Sandric, Legrain Magalie, Levaillant Romain, Simon Michel, Lafite Robert (2020). Data from marine grab samples collected during the AUPASED surveys. SEANOE. https://doi.org/10.17882/74515


In addition to properly cite this dataset, it would be appreciated that the following work(s) be cited too, when using this dataset in a publication :


Michel Guillaume, Le Bot Sophie, Lesourd Sandric, Lafite Robert Morpho-sedimentological and dynamic patterns in a ria type estuary: the Belon estuary (South Brittany, France). Journal of Maps IN PRESS. Publisher's official version : https://doi.org/10.1080/17445647.2021.1925170 , Open Access version : https://archimer.ifremer.fr/doc/00697/80932/
