(2024). Identification and Abundance of Barkley Canyon Megafauna: Daily Observations from 2012 to 2015 Using Ocean Network Canada Videos (BC, Canada). SEANOE. https://doi.org/10.17882/101374
Copy this text
Identification and Abundance of Barkley Canyon Megafauna: Daily Observations from 2012 to 2015 Using Ocean Network Canada Videos (BC, Canada)
This dataset provides comprehensive records of species identified and their daily abundance in three deep-sites (Upper Slope -400m, Wall -900m, and Axis -1000m) of the Barkley Canyon (British Columbia, Canada) from 2012 to 2015.
The data was collected through video recordings from the Ocean Network Canada observatory, which are publicly accessible using their SeaTube website.
The dataset includes:
- a detailed list of species = "species_list_match.csv"
- a corresponding table of species names = "Species_details.csv"
- daily abundance counts for each sites = "Abundance_SiteName.csv"
- a file that outlines the methodology used for identification and counting = "ReadMe.txt"
----------
Method:
- During each daily sampling, all 5-minute recordings made between 08:00 and 08:05 were viewed using VLC 2.0.1 © software to count and identify individuals at the lowest possible taxonomic level. All videos (2 minutes fixed + 3 minutes of scanning) were utilized. Videos were deemed unusable if viewing conditions were poor or particle counts were too high. When identification was not feasible, OTUs were defined.
On the three sites mentioned, a camera mounted on a tripod recorded continuously at 5-minute intervals each day of the year. During these recordings, the background was illuminated using two spotlights. The camera recorded fixedly for the initial two minutes and could rotate from 0° (stationary, upper slope, pod2) to 360° (full rotation, canyon axis pod1, except between August 2014 and January 2015) and 180° (canyon wall, pod4). The illumination and zoom parameters, adjustable via the ONC site, were not consistent across all sites and sampling periods, affecting the observed surface area, ranging from 0.5 m² (upper slope, pod2 between May 2013 and May 2014) to a maximum of 9 m² (canyon axis, pod1 between mid-2013 and February 2014). The surface area was calculated each time the camera settings were changed (usually during annual maintenance missions) using a scaling grid developed from the camera’s two lasers, fixing a width of 10 cm on the ground as measured in the camera's field of view. Image captures were taken at intervals to cover the entire surface swept by the camera during rotation, estimating the sampled surface by overlaying the scaling grid on each image.
- For more details on the methodology and to understand the context in which the data were collected (scientific questions, hypotheses, and studies conducted), you can refer to Pauline Chauvet's thesis (available in open access).
Disciplines
Biological oceanography
Keywords
North East Pacific Ocean, Deep-Sea, Deep-Sea Canyon, Megafauna, Cameras, Observatory, ONC, IUEM, Bottom video, Anoplopoma fimbria, Chionoecetes tanneri, Sebastes, Epibenthic fauna
Location
48.904745N, 47.817146S, -125.197449E, -127.339783W
Devices
Canyon axis camera 2012-06: https://data.oceannetworks.ca/Sites?observatoryId=8&siteId=100255
SubAqua Imaging Systems Inc..P/N 0343-001-01 S/N 001 is for the system, put together by Subaqua Imaging Systems, Inc. S/N 00408CB52C86 is for the camera itself 5-megapixel resolution at 12 fps and full HDTV 1080p, P-Iris control and day/night functionality, multi-view streaming, digital PTZ and guard tour. Easy installation with Power over Ethernet and remote back focus, multiple H.264 and motion JPEG video streams- 2018-01-22 22:00:07- contact = Reyna Jenkyns at Ocean Network Canada
Canyon axis camera 2013-05 : https://data.oceannetworks.ca/Sites?observatoryId=8&siteId=1000048
DragonfishSubC Imaging. The SubC Dragonfish is an HD video and digital stills camera. It has the capability of live HD video transmission over 4-wire Ethernet and the recording of 5MP digital stills or HD (1080p) video to the cameras internal internal memory.-2013-04-08 23:35:59- contact = Meghan Tomlin at Ocean Network Canada
Canyon axis camera 2014-05 : https://data.oceannetworks.ca/DeviceListing?DeviceId=23152
DragonfishSubC Imaging. The SubC Dragonfish is an HD video and digital stills camera. It has the capability of live HD video transmission over 4-wire Ethernet and the recording of 5MP digital stills or HD (1080p) video to the cameras internal internal memory.-2013-04-08 23:35:59-contact = Meghan Tomlin at Ocean Network Canada
Canyon upper slope camera 2012-06 : https://data.oceannetworks.ca/Sites?observatoryId=8&siteId=100238
DragonfishSubC ImagingThe SubC Dragonfish is an HD video and digital stills camera. It has the capability of live HD video transmission over 4-wire Ethernet and the recording of 5MP digital stills or HD (1080p) video to the cameras internal internal memory.2012-09-20 22:59:46- contact = Richard Riddell at Ocean Network Canada
Canyon upper slope camera 2013-05 : https://data.oceannetworks.ca/Sites?observatoryId=8&siteId=1000051
DragonfishSubC ImagingThe SubC Dragonfish is an HD video and digital stills camera. It has the capability of live HD video transmission over 4-wire Ethernet and the recording of 5MP digital stills or HD (1080p) video to the cameras internal internal memory.2013-04-08 23:35:22 - contact = Meghan Tomlin at Ocean Network Canada
Canyon upper slope camera 2014-05 : https://data.oceannetworks.ca/Sites?observatoryId=8&siteId=1000254
DragonFishSubC ImagingThe SubC Dragonfish is an HD video and digital stills camera. It has the capability of live HD video transmission over 4-wire Ethernet and the recording of 5MP digital stills or HD (1080p) video to the camera internal internal memory -.2020-04-08 21:55:58- contact = Reyna Jenkyns at Ocean Network Canada
Canyon wall camera 2012-05 : https://data.oceannetworks.ca/Sites?observatoryId=8&siteId=100158
SubAqua Imaging Systems Inc.P/N 0343-001-01 S/N 001 is for the system, put together by Subaqua Imaging Systems, Inc. S/N 00408CB52C86 is for the camera itself 5-megapixel resolution at 12 fps and full HDTV 1080p, P-Iris control and day/night functionality, multi-view streaming, digital PTZ and guard tour. Easy installation with Power over Ethernet and remote back focus, multiple H.264 and motion JPEG video streams -2018-01-22 22:00:07- contact = Reyna Jenkyns at Ocean Network Canada
Canyon wall camera 2013-05 : https://data.oceannetworks.ca/Sites?observatoryId=8&siteId=1000056
SubAqua Imaging Systems Inc.P/N 0343-001-01 S/N 001 is for the system, put together by Subaqua Imaging Systems, Inc. S/N 00408CB52C86 is for the camera itself 5-megapixel resolution at 12 fps and full HDTV 1080p, P-Iris control and day/night functionality, multi-view streaming, digital PTZ and guard tour. Easy installation with Power over Ethernet and remote back focus, multiple H.264 and motion JPEG video streams -2018-01-22 22:00:07- contact = Reyna Jenkyns at Ocean Network Canada
Canyon wall camera 2014-05 : https://data.oceannetworks.ca/Sites?observatoryId=8&siteId=1000261
SubAqua Imaging Systems Inc.P/N 0343-001-01 S/N 001 is for the system, put together by Subaqua Imaging Systems, Inc. S/N 00408CB52C86 is for the camera itself 5-megapixel resolution at 12 fps and full HDTV 1080p, P-Iris control and day/night functionality, multi-view streaming, digital PTZ and guard tour. Easy installation with Power over Ethernet and remote back focus, multiple H.264 and motion JPEG video streams - 2018-01-22 22:00:07- contact = Reyna Jenkyns at Ocean Network Canada
Data
| File | Size | Format | Processing | Access | |
|---|---|---|---|---|---|
Abundance of species identified in the axis (1000 m depth) of Barkley Canyon (BC, Canada) | 77 Ko | CSV | Quality controlled data | ||
Abundance of species identified in the upper slope (400 m depth) of Barkley Canyon (BC, Canada) | 64 Ko | CSV | Quality controlled data | ||
Abundance of species identified in the wall (900 m depth) of Barkley Canyon (BC, Canada) | 21 Ko | CSV | Quality controlled data | ||
Description file including the method used and related resources to fully understand the dataset | 4 Ko | TEXT | |||
Information and relation table on species identification and name | 4 Ko | CSV | |||
List of the species Identified (we used WoRMS Taxon match tool to verify the species names, ID and classifications) | 6 Ko | CSV | Processed data |
