Hydrography and currents in Storfjorden (Svalbard) from the STEP 2016-2017 moorings

Date 2019
Temporal extent 2016-07-14 -2017-09-28
Author(s) Vivier FredericORCID1, Lourenco Antonio1, Michel Elisabeth2, Pruchon Abel3
Affiliation(s) 1 : CNRS, LOCEAN-IPSL, Sorbonne Université
2 : CEA
3 : Ecole Centrale Nantes
DOI 10.17882/62632
Publisher SEANOE
Keyword(s) Svalbard, Storfjord, Polynya, Mooring, current, temperature, salinity, oxygen, backscatter
Abstract

As part of the STeP project (STorfjorden Polynya multidisciplinary study), two moorings, M1 and M2, were deployed in Storfjorden (Svalbard) on July 14, 2016 from the French R/V L’Atalante and were recovered one year later, on September 28, 2017, from the French R/V Pourquoi-Pas?. The two moorings, deployed a few hundred meters apart at 78°N and 20°E at a depth of 100m, documented the formation of dense Brine-enriched Shelf Water (BSW).

The moorings included both physical oceanography (PO) and biogeochemistry sensors. The present dataset is composed of PO data only: the 3 components of the currents, backscatter, salinity, temperature and dissolved oxygen. PO sensors on M1, spanning the whole water column, included 6 Seabird SBE37 microcat (CTD),  15 RBR solo (T), and 1 RBR duet (TD) for hydrography, while currents were monitored with a RDI WH 300kHz upward looking ADCP and 1 Nortek Aquadopp underneath. PO sensors on the shorter M2 mooring included 1 Seabird SBE63 (CTD-O2), 1 RBR solo (T) and 1 RBR duo (TD).

Data have been calibrated and validated and the different steps of this processing are discussed in the technical report provided with the dataset. Two netcdf4 files are provided for M1: one for hydrography (STEP2016_M1_hydrography.nc), the other one (STEP2016_M1_current.nc)  for currents and backscatter. Only one netcdf4 files (STEP2016_M2_hydrography.nc) is provided for the shorter M2. Temperature and salinity data from SBE sensors have been interpolated on a common time grid with a 20’ time step. Likewise temperature data from RBR are provided on a 30” time grid. A merged SBE-RBR dataset has also been built for increased vertical resolution, providing temperature every 20’. ADCP data are provided on a 100’ time grid. The user is referred to the technical report provided with the dataset for further information on the different fields.

Licence CC-BY-NC
Utilisation While our best effort was put in the processing and publication of this data set, intended to be research-quality, we provide no warranty whatsoever. The user takes full responsibility of his/her use of the data.
Acknowledgments We gratefully acknowledge support from the French Oceanographic Fleet (FOF) for deployment and recovery cruises (STEP 2016 R/V L'Atalante; STEP-recup 2017 R/V Pourquoi Pas?) as well as from CNRS/INSU and IPEV.
Sensor metadata

PLEASE REFER TO THE PDF MANUAL PROVIDED WITH THE DATASET

Mooring M1 includes (for physical oceanography):

- hydrography: 6  Seabird SBE37 microcat (CTD),  15 RBR solo (T), and 1 RBR duet (TD)

- currents: 1 RDI WH 300kHz upward looking ADCP, 1 Nortek Aquadopp

Mooring M2 includes (for physical oceanography):

-hydrography: 1 Seabird SBE63 (CTD-02), 1 RBR solo (T), 1 RBR duo (TD).

Data
File Size Format Processing Access
312 KB PDF Access on demand until 2021-11-14
16 MB NC, NetCDF Processed data Access on demand until 2022-04-03
331 MB NC, NetCDF Processed data Access on demand until 2022-04-03
146 MB NC, NetCDF Processed data Access on demand until 2022-04-03
Top of the page

How to cite

Vivier Frederic, Lourenco Antonio, Michel Elisabeth, Pruchon Abel (2019). Hydrography and currents in Storfjorden (Svalbard) from the STEP 2016-2017 moorings. SEANOE. https://doi.org/10.17882/62632
