Across-shelf mooring array from the northeast shelf of New Zealand

Date 2015-05
Author(s) O'Callaghan JoanneORCID1, Brewer MikeORCID1, Elliott Fiona1, 2
Affiliation(s) 1 : NIWA, National Institute of Water and Atmospheric Research, New Zealand
2 : University of Bergen, Norway
DOI 10.17882/78971
Publisher SEANOE
Keyword(s) ADCP, Seabird 37 Microcat, New Zealand, Moorings, NE Shelf

Five cross-shelf oceanographic moorings (M1 - M5) were deployed along Topex/Poseidon 147 line in water depths spanning 80to 1865 m (Fig. 1a). The stations, M1 (80 m depth) and M2 (130 m) were on the continental shelf, M3 (438 m) the shelf break,M4 (1105 m) the continental slope, and the most offshore M5 (1865 m) on the continental rise. The deployments lasted longerthan a year and the measurements overlap between 11/5/2015 and 15/5/2016. A total of 46 instruments were installed in the array of moorings (Fig. 1). Long Range (LR) acoustic Doppler current profilers (ADCPs) (75Hz) were deployed at stations M3, M4, and M5, and 4 Workhorse (WH) ADCPs (300 or 600Hz) were installed near the bottom at M1 and M2, and near thesurface at M4 and M5 and covered the water column shown in red and blue in Fig. 1b. The water column was binned every 4 m(WH) or 15 m (LR) by upward looking ADCPs. All the stations, except M1, had between 4 and 10 SBE 56 temperature sensors (black dots in Fig. 1b) and 2 or 3 MicroCAT CTDs (green circles in Fig. 1b). The temperature sensors were deployed every 10m in the upper 100 m and then every 50 m below that. M2 and M3 had CTDs placed near the surface and bottom, whereas M4and M5 had additional CTD at 200 m depth. Velocity (temperature and salinity) measurements were taken during a period of 2min. (1 min.) every 10 min or less.

Licence CC-BY-NC
Acknowledgements We are grateful to the Master and crew of the RV Tangaroa on TAN1506 and TAN1604. Funding was provided by NIWA Strategic Science Investment Fund (SSIF) Ocean-Climate Interactions Programme and Flows + Productivity Programme
Sensor metadata

RDI ADCP, Seabird 37 and Seabird 56 instruments

File Size Format Processing Access
ADCP, SBE37 and SBE56 instruments from five moorings deployed across the NE Shelf of New Zealand 769 MB matlab data Quality controlled data Open access
Top of the page

How to cite

O'Callaghan Joanne, Brewer Mike, Elliott Fiona (2015). Across-shelf mooring array from the northeast shelf of New Zealand. SEANOE.
