Array of Ocean Bottom Tilt Current Meters: data from the EMSO-Azores observatory, 2021-2022
This dataset contains current data acquired between june 2021 and June 2022 using 5 TCM-3 Ocean Bottom Tilt Current Meters installed next to the Tour Eiffel, Montségur and Crystal hydrothermal vent sites.
The TCM-3 Ocean Bottom Tilt Current Meter from Lowell Instruments LLC (North Falmouth, MA, USA) measures current using the drag-tilt principle. The logger is buoyant and is anchored to the bottom via a short flexible tether. Drag from moving water tilts the logger in the direction of flow. The logger’s accelerometer and magnetometer channels are used to record the amount of tilt and direction of tilt (compass bearing). The array comprises 6 TCM-3 currentmeters, deployed near the Tour Eiffel, Montségur and Crystal hydrothermal vent sites. It is not connected to an energy node. The currentmeter's internal clocks are set to UTC time before deployment. Clock drift after recovery is not implemented in data but added as metadata in the metadata file.
Data are provided for each deployed instrument as two text files:
- current data
- temperature data
Disciplines
Physical oceanography
Keywords
Mid-Atlantic Ridge, EMSO-Azores, EMSO, Hydrothermal Vents, Lucky Strike, Eiffel Tower, Crystal, Montsegur, current velocity, current direction, near seafloor seawater temperature, Time-series, MoMARSAT2019, MoMARSAT2021, MoMARSAT2022.
Location
37.290817N, 37.288383S, -32.27543E, -32.28178W
Devices
Parameters
- temperature (°C)
- current velocity (m/s)
- current direction (° from magnetic N)
Location
- Regional node: Emso-Azores
- Site: Lucky Strike hydrothermal field
Coordinates: see the metadata file.
Installation
Cruise: MATABOS, Marjolaine and SARRAZIN Jozée, MOMARSAT2021 cruise, Atalante, https://doi.org/10.17600/18001296
Recovery
Cruise: SARRADIN Pierre-Marie and MATABOS, Marjolaine, MOMARSAT2022 cruise, Pourquoi Pas?, https://doi.org/ 10.17600/18001914
Operating parameters
For deployments near selected hydrothermal vents at the EMSO-Azores observatory, the accelerometer and magnetometer are configured with a burst interval of 1 minute, a burst rate of 8 Hz and a burst duration of 15 seconds. Temperature are recorded with a period of 1 minute.
Sensor metadata
The specifications of the magnetometer, accelerometer and temperature probes are as follows:
- magnetometer: 3-axis magnetoresistive sensor and 12-bit A/D Converter, range +/- 1.3 Gauss, accuracy +/- 1° typical (nominal compass bearing), resolution < 0.001 Gauss, maximum recording rate 64 Hz, measurement duration 6 mS
- accelerometer: 3-axis MEMS Accelerometer and 10-bit A/D Converter, software averaging: up to 32 values per measurement (25 samples per measurement are averaged when recording at 64 Hz), range +/- 2 g, accuracy < 0.01 g (enables 1° inclination determination), resolution < 0.001 g, maximum recording rate 64 Hz, measurement duration 0.625 ms per sample, 32 samples per recorded value (15.6 ms total sample time at 64 Hz 20 ms at 32 Hz or less)
- thermistor: NTC Thermistor and 16-bit A/D Converter, low-pass filter rejects 50/60 Hz noise, range -5 to 30 °C (standard), -20 to 50 °C (extended), accuracy +/-0.1 °C (standard), +/-0.2 °C (extended), resolution < 0.01 °C, maximum rate 1 Hz, time constant 4 minutes typical (when plunged into an ice bath).
Sensor setup
Test and calibration A set of calibration coefficients for the magnetometer, accelerometer, and temperature channels are stored in the logger. The magnetometer and accelerometer coefficients are unique to each instrument while temperature coefficients are specific to each manufacturing lot. The calibration coefficients are applied upon recovery when the binary data is converted to text data. Data is provided as text, and not corrected for the time drift. Time drift is provided as metadata in Table_TCM3EMSO_Azores2021_2022.docx
Data management
- Real time data transmission: No
- Data storage in the Communication and storage unit (COSTOF2): No
- Data storage in the instrument: Full
Data
Alternative access to data
| File | Size | Format | Processing | Access | end of embargo | |
|---|---|---|---|---|---|---|
Metadata | 47 Ko | - | ||||
Data | 23 Mo | CSV | Raw data | 2024-11-01 | ||
Current data TCM3-1_2021 | 5 Mo | NetCDF | Raw data | 2024-11-01 | ||
Current data TCM3-3_2021 | 6 Mo | NetCDF | Raw data | 2024-11-01 | ||
Current data TCM3-B_2021 | 1 Mo | NetCDF | Quality controlled data | 2024-11-01 | ||
Current data TCM3-C_2021 | 1 Mo | NetCDF | Raw data | 2024-11-01 | ||
Current data TCM3-D_2021 | 6 Mo | NetCDF | Raw data | 2024-11-01 |
