(2023). COSTOF2, technical data from SeaMoN East, node of the EMSO-Azores observatory, 2019-2020. SEANOE. https://doi.org/10.17882/93994
Copy this text
COSTOF2, technical data from SeaMoN East, node of the EMSO-Azores observatory, 2019-2020
This dataset contains technical parameters (Voltage in V, current in mA, energy in Ah, internal pressure in mbar, water leak detection). This day log starts on june 19th 2019, stops on septembre 15th 2020 and is done by the COSTOF2 (COmmunication and STOrage Front-end). It is the Electronic core of SeaMoN East, the bottom station of EMSO-Azores dedicated to biological observations.
Disciplines
Environment, Physical oceanography, Biological oceanography, Chemical oceanography
Keywords
Mid-Atlantic Ridge, EMSO, Lucky Strike, Time-series, Biological monitoring node, MoMAR, SeaMon East, deep sea, SMOOVE, COSTOF
Location
37.288N, 37.288S, -32.275E, -32.275W
Devices
Parameters
- Time
- Latitude
- Longitude
- Voltage (mV)
- Consumed energy (mAh)
- Water (leak) detection
- Separator : Slot 8
- Slot 8 current (mA)
- Slot 8 internal temperature
- Slot 8 Internal pressure
- Slot 8 SD card free space (bytes)
- Separator : Slot 9
- Slot 9 current (mA)
- Slot 9 internal temperature
- Slot 9 Internal pressure
- Slot 9 SD card free space (bytes)
- Separator : Slot 10
- Slot 10 current (mA)
- Slot 10 internal temperature
- Slot 10 Internal pressure
- Slot 10 SD card free space (bytes)
- Separator : Slot 11
- Slot 11 current (mA)
- Slot 11 internal temperature
- Slot 11 Internal pressure
- Slot 11 SD card free space (bytes)
- Separator : Slot 15
- Slot 15 current (mA)
- Slot 15 internal temperature
- Slot 15 Internal pressure
- Slot 15 SD card free space (bytes)
Location
- Regional node: Emso-Azores
- Site: Lucky Strike
- Node: Seamon East
- Coordinates: 37.288N, -32.275E
- Depth: 1700 m
Installation
- Cruise: SARRADIN Pierre-Marie, CANNAT Mathilde (2017) MOMARSAT2019 cruise, RV Pourquoi pas ?, https://doi.org/10.17600/18001110
- Dive: 1953/27/15 (27/06/2019)
Recovery
- Cruise: Pierre Marie Sarradin - Ifremer / REM, Julien Legrand - Ifremer /REM - MOMARSAT2020 cruise, N/O Pourquoi Pas ? https://doi.org/10.17600/18000684
- Dive: N° 753-1, september 13, 2020 18 :52
Operating parameters
- Measurement duration: 10 sec
- Sampling period: 60 minutes
Sensor metadata
- Type: Communication and Storage Front-end 2
- Provider: IFREMER
Data
| File | Size | Format | Processing | Access | |
|---|---|---|---|---|---|
data | 808 Ko | CSV | Raw data |
How to cite
Gautier Laurent
