Data for Typology of Plankton Communities seen by In Situ Imaging in the First 500 m of the Global Ocean

Supporting data for the paper "Three major mesoplanktonic communities resolved by in situ imaging in the upper 500 m of the global ocean"

The distribution of mesoplankton communities have been poorly studied at global scale, especially from in situ instruments. This study aims  to (1) describe the global distribution of mesoplankton communities in relation with their environment and (2) assess the ability of various environmental-based ocean regionalisations to explain the distribution of these communities.

Global ocean, 0 - 500 m depth.

Time period
2008 - 2019

Major taxa studied
28 groups of large mesoplanktonic and macroplanktonic organisms, covering Metazoa, Rhizaria and Cyanobacteria.

From a global data set of 2500 vertical profiles making use of the Underwater Vision Profiler 5 (UVP5), an in situ imaging instrument, we studied the global distribution of large (> 600 µm) mesoplanktonic organisms. Among the 6.8 million imaged objects, 330,000 were large zooplanktonic organisms and phytoplankton colonies, the rest consisting of marine snow particles. Multivariate ordination (PCA) and clustering were used to describe patterns in community composition, while comparison with existing regionalisations was performed with regression methods (RDA).

Within the observed size range, epipelagic plankton communities were Trichodesmium-enriched in the intertropical Atlantic, Copepoda-enriched at high latitudes and in upwelling areas, and Rhizaria-enriched in oligotrophic areas. In the mesopelagic layer, Copepoda-enriched communities were also found at high latitudes and in the Atlantic Ocean, while Rhizaria-enriched communities prevailed in the Peruvian upwelling system and a few mixed communities were found elsewhere. The comparison between the distribution of these communities and a set of existing regionalisations of the ocean suggested that the structure of plankton communities described above is mostly driven by basin-level environmental conditions.

Main conclusions
In both layers, three types of plankton communities emerged and seemed to be mostly driven by regional environmental conditions. This work sheds light on the role not only of metazoans, but also of unexpected large protists and cyanobacteria in structuring large mesoplankton communities.


Biological oceanography


biogeography, global ocean, in situ imagery, plankton communities, spatial distribution, Trichodesmium, Rhizaria, Copepoda


Environmental, plankton and particle data averaged across epipelagic and upper mesopelagic layer for each profile.
848 KoCSVProcessed data
How to cite
Panaïotis Thelma, Babin Marcel, Biard Tristan, Carlotti François, Coppola Laurent, Guidi Lionel, Hauss Helena, Karp-Boss Lee, Kiko Rainer, Lombard Fabien, McDonnell Andrew MP, Picheral Marc, Rogge Andreas, Waite Anya M, Stemmann Lars, Irisson Jean-Olivier (2023). Data for Typology of Plankton Communities seen by In Situ Imaging in the First 500 m of the Global Ocean. SEANOE.

Copy this text
