MOOSE HF radar daily averaged surface currents from MEDTLN site (Toulon NW Med)

In the framework of the SNO/SOERE MOOSE (Mediterranean Ocean Observing System on Environment) program, the Mediterranean Institute of Oceanography is operating coastal High Frequency Surface Wave Radars (HF radar) on the North Western Mediterranean coast. HF radar provide high resolution (3­-5 km), synoptic view of surface currents from the shore up to 80 km off shore at hourly time scales. The measurement principle is based on the Doppler effect created by an additional current on the intrinsic speed of the waves selected by radar-sea interactions, called Bragg waves, having a wavelength of half that of the radar e.m. waves and propagating in the axis of observation (radial currents). A single radar scans the sea in azimuth and determines the radial components of the current at each adjacent cell along each azimuth. Two separate radars for the same area from different angles then collect the information necessary for mapping vector current from the combination of the two sets of radial components.

The MOOSE HF radar MEDTLN data set is made of daily averaged surface currents, geo-referenced on Cartesian lon/lat coordinates. Those are computed from hourly total velocity data of level L3B (velocity threshold and GDOP threshold tests passed) for which additional RFI outliers’ eliminations are made using a one inertial period (17h at 43°N) statistical method based on the number of L3B valid data, variance and mean over the 17h period by reference to the long term (full dataset) statistics. The associated quality control (QC) indexes for the hourly data range from 0 (missing or bad values) to 4 (best confidence values). Details of the method available on the MOOSE HFradar website. Velocities, variances and QC values in this file are those averaged on a lunar daily basis (25 hours average) centered at noon of each day. Hourly data for specific studies may be available on equest (see contacts below).

In the framework of the SNO/SOERE MOOSE (Mediterranean Ocean Observing System on Environment) program, the Mediterranean Institute of Oceanography is operating coastal High Frequency Surface Wave Radars (HF radar) on the North Western Mediterranean coast. HF radar provide high resolution (3­-5 km), synoptic view of surface currents from the shore up to 80 km off shore at hourly time scales. The measurement principle is based on the Doppler effect created by an additional current on the intrinsic speed of the waves selected by radar-sea interactions, called Bragg waves, having a wavelength of half that of the radar e.m. waves and propagating in the axis of observation (radial currents). A single radar scans the sea in azimuth and determines the radial components of the current at each adjacent cell along each azimuth. Two separate radars for the same area from different angles then collect the information necessary for mapping vector current from the combination of the two sets of radial components.

The MOOSE HF radar MEDTLN data set is made of daily averaged surface currents, geo-referenced on Cartesian lon/lat coordinates. Those are computed from hourly total velocity data of level L3B (velocity threshold and GDOP threshold tests passed) for which additional RFI outliers’ eliminations are made using a one inertial period (17h at 43°N) statistical method based on the number of L3B valid data, variance and mean over the 17h period by reference to the long term (full dataset) statistics. The associated quality control (QC) indexes for the hourly data range from 0 (missing or bad values) to 4 (best confidence values). Details of the method available on the MOOSE HFradar website. Velocities, variances and QC values in this file are those averaged on a lunar daily basis (25 hours average) centered at noon of each day. Hourly data for specific studies may be available on equest (see contacts below).

Disciplines

Physical oceanography

Keywords

Current, HF-Radar

Location

43.1N, 42.4S, 6.7E, 5.7W

Devices

WERA  (Wellen  Radar - Helzel Messtechnik GmbH) operated at 16.1-16.2 MHz - 50 kHz bandwidth (3km range resolution) - 8 receiving antennas and MUSIC Direction Finding (2° azimuthal resolution) in monostatic (Peyras site) and bistatic (Benat-Porquerolles site) configuration. Vector component gridded on a 2km X 2km Cartesian regular grid. More details of the intallation and acquisition protocols can be found on the real-time dedicated web site http://hfradar.univ-tln.fr/ and in Quentin et al. 2014.7th EuroGOOS Conference Proceedings, Oct 2014, Lisboa, Portugal Buch E, Antoniou Y, Eparkhina D, Nolan G (Eds.) ISBN 978-2-9601883-1-8, pp 111-118.

Data

FileSizeFormatProcessingAccess
2012-2014 data
12 MoNetCDFQuality controlled data
How to cite
Zakardjian Bruno, Quentin Céline (2018). MOOSE HF radar daily averaged surface currents from MEDTLN site (Toulon NW Med). SEANOE. https://doi.org/10.17882/56500
In addition to properly cite this dataset, it would be appreciated that the following work(s) be cited too, when using this dataset in a publication :
Quentin C., Barbin Y., Bellomo L., Forget P., Mallarino D.,Marmain J., Molcard A., Zakardjian B. (2014). High Frequency Surface Wave Radar in the French Mediterranean Sea: an element of the Mediterranean Ocean Observing System for the Environment. 7th EuroGOOS Conference Proceedings, Oct 2014, Lisboa, Portugal Buch E, Antoniou Y, Eparkhina D, Nolan G (Eds.) ISBN 978-2-9601883-1-8, hal-01131489. https://hal.archives-ouvertes.fr/hal-01131489
