Experimental database of the flow past a wall-mounted square cube

Date 2019
Temporal extent 2016-05 -2017-07
Author(s) Ikhennicheu MariaORCID1, Germain GregoryORCID1, Gaurier BenoitORCID1
Affiliation(s) 1 : IFREMER, Marine Structures Laboratory, Boulogne-sur-mer, France
DOI 10.17882/61819
Publisher SEANOE
Keyword(s) Wall-mounted cube, PIV, LDV, Bathymetry
Abstract

In high flow velocity areas like those suitable for tidal applications, turbulence intensity is high and flow variations may have a major impact on tidal turbines behaviour. Large turbulent structures are present in the water column and may interact with the tidal turbine. The Reynolds number, based on the rugosity height and mean flow velocity, is rather high in this context: Re=2.5x107. For that purpose, experiments are carried out in a flume tank with Re as high as achievable in Froude similitude (in the tank: Re=2.5x105 and Fr=0.23) in order to study the wake past seabed obstacles. The obstacle is here a canonical square wall-mounted cube chosen to be representative of specific in-situ bathymetric variations. To represent the variability of turbulent in-situ conditions, different upstream turbulence rate are achieved. Using PIV and LDV measurements, the flow past the cube is investigated. The experimental database is presented in this report.

Licence CC-BY-NC
Utilisation Data are published without any warranty, express or implied. The user assumes all risk arising from his/her use of data. Data are intended to be research-quality and include estimates of data quality and accuracy, but it is possible that these estimates or the data themselves contain errors. It is the sole responsibility of the user to assess if the data are appropriate for his/her use, and to interpret the data, data quality, and data accuracy accordingly. Authors welcome users to ask questions and report problems.
Data
File Size Format Processing Access
ReadMe 1 MB PDF Open access
Data 15 GB TEXTE Raw data Open access
Top of the page

How to cite

Ikhennicheu Maria, Germain Gregory, Gaurier Benoit (2019). Experimental database of the flow past a wall-mounted square cube. SEANOE. https://doi.org/10.17882/61819
