Spatial distribution of megabenthic communities and associated diversity in Cap de Creus continental shelf and submarine canyon (NW Mediterranean)

Date 2022-07-28
Temporal extent 2007 -2014
Author(s) Dominguez-Carrió CarlosORCID1, 2, Riera Joan LluísORCID3, Robert KatleenORCID4, 5, Zabala Mikel3, Requena SusanaORCID1, 6, Gori AndreaORCID3, Orejas CovadongaORCID8, 9, Lo Iacono ClaudioORCID1, 4, Estournel ClaudeORCID7, Corbera GuillemORCID1, Ambroso Stefano1, Uriz Maria Jesús10, López-González Pablo J.ORCID11, Sardá RafaelORCID10, Gili Josep-MariaORCID1
Affiliation(s) 1 : Institut de Ciències del Mar, Consejo Superior de Investigaciones Científicas (ICM-CSIC), Passeig Marítim de la Barceloneta 37-49, 08003, Barcelona, Spain
2 : Instituto de Investigação em Ciências do Mar - Okeanos, Departamento de Oceanografia e Pescas, Universidade dos Açores, Rua Prof. Doutor Frederico Machado 4, 9901-862, Horta, Portugal
3 : Departament de Biologia Evolutiva, Ecologia i Ciències Ambientals, Facultat de Biologia, Universitat de Barcelona, Avinguda Diagonal 643, 08028, Barcelona, Spain
4 : National Oceanography Centre, University of Southampton Waterfront Campus, European Way, SO14 3ZH, Southampton, UK
5 : Fisheries and Marine Institute of Memorial University, 155 Ridge Rd, St. John's, NL A1C 5R3, Canada
6 : RSPB, Centre for Conservation Science, The Lodge, Sandy SG19 2DL, Bedfordshire, UK
7 : Laboratoire d’Etudes en Géophysique et Océanographie Spatiales (LEGOS), CNRS/UPS/CNES/IRD, Avenue Edouard Belin 14, 31400, Toulouse, France
8 : Instituto Español de Oceanografía, Centro Oceanográfico de Gijón (IEO-CSIC), Avenida Príncipe de Asturias 70 bis, 33212 Gijón, Spain
9 : Hanse-Wissenschatfskolleg – Institute for Advanced Study (HWK), Lehmkuhlenbusch 4, 27753 Delmenhorst, Germany
10 : Centre d’Estudis Avançats de Blanes, Consejo Superior de Investigaciones Científicas (CEAB-CSIC), Carrer d’accés a la Cala Sant Francesc 14, 17300, Blanes, Spain
11 : Biodiversidad y Ecología Acuática, Departamento de Zoología, Facultad de Biología, Universidad de Sevilla, Reina Mercedes 6, 41012, Sevilla, Spain
DOI 10.17882/89630
Publisher SEANOE
Keyword(s) Invertebrate megafauna, Cold-water corals, Sponge grounds, Underwater images, Community analysis, Habitat mapping, Random Forest, Biodiversity, Natura 2000 Network
Abstract

In 2014, the continental shelf and submarine canyon off Cap de Creus (NW Mediterranean) were included in the Site of Community Importance (SCI) “South-West Gulf of Lions canyons system” of the Natura 2000 Network of protected areas. Before the declaration of the SCI (2007-2103), 60 underwater video transects were performed in the area by means of ROVs and a manned submersible, covering more than 30 km of seafloor. Based on the annotation of the video images, we identified the main invertebrate megabenthic communities dwelling from the shelf (70 m depth) down to the bottom of the canyon head (400 m depth). The results of the multivariate analyses indicated that this marine area hosted several benthic communities dominated by suspension- and filter-feeding species, including octocoral gardens, soft-coral assemblages, crinoid fields, sponge grounds and cold-water corals. This dataset includes (1) the geographical location of the benthic communities identified in the video footage, as determined by the clustering analysis, (2) the intra-community diversity associated to the benthic communities, provided as the number of megafauna species identified in each sampling unit and the exponential of Shannon, and (3) the spatial distribution of the benthic communities mapped by means of the Random Forest classification algorithm. This dataset is related to the article “Diversity, structure and spatial distribution of megabenthic communities in Cap de Creus continental shelf and submarine canyon (NW Mediterranean)” submitted to Progress in Oceanography by Dominguez-Carrió et al., which contains further information on how the data were obtained and processed.

Licence CC-BY-NC-SA
Acknowledgements This dataset was obtained in the framework of the European projects HERMES (Goce-CT-2005-511234-I) and Life+ INDEMARES (LIFE07/NAT/E/000732), and the Spanish projects DEEP CORAL (CTM2005-07756-C02-02/MAR) and the Acciones Complementarias (CTM2005-24174-E, CTM2006-27063-E/MAR, CTM2007-28758-E/MAR). The authors thank the crew of the research vessel García del Cid and all scientists and technicians who participated in the DEEP CORAL, HERMES and INDEMARES cruises. We also thank Gavin Newman (ROV pilot) and the members of the JAGO Team Jürgen Schauer and Karen Hissmann (Geomar, Kiel) for the acquisition of the video footage, as well as the General Directorate of Fisheries Management of the Spanish Ministry of Agriculture, Food and Environment (MAGRAMA) for providing of the VMS data and to Dan Orange (AOA Geophysics Inc.) for the bathymetric data of the submarine canyon. CD-C acknowledges the financial support received by the EU funded projects Life+ INDEMARES (LIFE07/NAT/E/000732) and ENPI ECOSAFIMED (ENPI CBC MED 2007-2013) and by the FCT-IP Project UIDP/05634/2020.
Data
File Size Format Processing Access
465 KB zip Processed data Access on demand until 2022-12-01
Top of the page

How to cite

Dominguez-Carrió Carlos, Riera Joan Lluís, Robert Katleen, Zabala Mikel, Requena Susana, Gori Andrea, Orejas Covadonga, Lo Iacono Claudio, Estournel Claude, Corbera Guillem, Ambroso Stefano, Uriz Maria Jesús, López-González Pablo J., Sardá Rafael, Gili Josep-Maria (2022). Spatial distribution of megabenthic communities and associated diversity in Cap de Creus continental shelf and submarine canyon (NW Mediterranean). SEANOE. https://doi.org/10.17882/89630
